HYDER 25ton Heavy duty Forklift truck for wholesale

FD250

1. The shape of the whole machine adopts European design, the shape and structure are ergonomic, and the lines are beautiful and smooth.

2. The domestic components are selected from domestic well-known brands, standardized and standard, cost-effective, and reduce after-sales costs



3. Widely used in airports, ports, docks, stations, warehouses, large factories, and mines for loading and unloading, stacking, and handling

Inquiry Now

Descriptions



Item     Specifications
  XHC-250
            Features / Rated Load Kg 25000
Load Center mm 1220
Wheelbase mm 4400
 Weight  Weight kg  35000
        Chassis  Tire Specs:Front   14.00-24
 Tire Specs:Rear   14.00-24
/X- Tires Qty,front/rear(X-dreve wheels)   4/2
 Wheel tread:Front mm 2220
 Wheel tread:Rear mm 2300
  Dimensions // Mast/carriage tilt angle(front/rear) Degree(°) 6/12
 Mast height(fork lowering) mm 3970
 Mast lifting height mm 4000
 Max.height mm 5940
height to head guard(height to cab) mm 3440
Overall heightwith forks)                                       mm 8950
Fork front verticaal sueface to the rear end of the vehicle  mm 6550
 Overall width mm 3060
 Fork dimension mm 2400*300*100
 Fork carriage width mm 2800
  Mast min ground(with load) mm 350
   Wheelbase center min ground(with load) mm 420
 Min.turning Radius mm 6160
/Travel speed(with load/without load) km/h 25/30
Performance /Max.lifting speed(with load/without load) mm/s 260/270
 tractionn KN 160
/gradeability(with load/without load) % 20/22
 Driving brake   Hydraulic clamp disvc
       Engine / Engine brand/model Optional one WeiChai Engine
  WD10G220E
Optional two Dongfeng cummins
 Rated Output 162(Kw)
Cylinder No 6
               Others /Transmission gears(Front/rear)   2/1
